DESCRIPTION
Stock Number
41001
Type
Coil Slitting Line
Brand
PRO-ECO
Year
1988
Material
Grain Orientated & Non- Grain Orientated Silicon Steel & Cold Rolled Steel
Shear Stress
100,000 PSI - Silicon stl.
60,000 PSI - C.R.S.
60,000 PSI - C.R.S.
Max. Yield Stress
80,000 PSI
Min. Yield Stress
30,000 PSI
Max. Coil Weight
(Entry) 50,000 lbs
(Exit) 50,000 lbs
(Exit) 50,000 lbs
Max. Coil Width
(Entry) 48 ins. nominal
(50 ins maximum)
(Exit) 48 ins.
(50 ins maximum)
(Exit) 48 ins.
Min. Coil Width
(Entry) 8 ins.
(Exit) 1 ins.
(Exit) 1 ins.
Max. Coil O.D.
(Entry) 72 ins.
(Exit) 72 ins.
(Exit) 72 ins.
Min. Coil O.D.
(Entry) 36 ins.
(Exit) 36 ins.
(Exit) 36 ins.
Coil I.D.
(Entry) 16 s 20 ins.
(Exit) 20 ins
(Exit) 20 ins
Max. Strip Thickness
.025 ins. - Silicon Steel
.050 ins. - C.R.S.
.050 ins. - C.R.S.
Min. Strip Thickness
.010 ins.
Line Speed
Constant Speed 1200 FPM
NOTES
In production
Upgraded Controls
Upgraded Controls
